Launch X431 Pad VII Pad7 Elite Diagnostic Tool 2 Years Free Update

Advantages of LAUNCH X431 PAD VII ELITE, Upgrade Your Repair Work

LAUNCH X431 PAD VII ELITE is an unexpected high-end diagnostic tool from LAUNCH, comes with the ADAS calibration function, 60+ service functions, TPMS service, and 8 extended modules functions. New Smartlink C VCI powers technicians a new diagnostic level without the limitation of diagnostic functions, tools, and vehicle types.

LAUNCH X431 PAD VII ELITE (PAD 7) Highlights:

1. The Advantages of LAUNCH X431 Tools about the Dealership-level ECU Programming & Coding Functions: Backup/Recover ECU Data; Manual & Automatic Options; Aftermarket Installation; Modification/Changeover.
2. Online Programming. Note: Please r each us to get the "X431 PADVII online programming activation method" & the instruction on how to use VPN to bypass IP restrictions to gain access to this feature for more models.
3. J2534 Reprogramming Using Smartlink C (As a Local J2534 PassThru device) Note: Reach us to get the J2534 Operation manual.
4. Topology Mapping
5. Supports gasoline cars and diesel heavy-duty trucks with Smarlink C (need to purchase truck software in 'Mall')
6. Support automotive communication protocols CAN/CANFD/DoIP and automotive communication standards J2534/D-PDU/RP1210
7. Support some car makes coverage till 2022, incl. BMW, Benz, VW, Audi, GM, Ford, Chrysler, Toyota, Nissan, Honda, Land rover etc. Full system vehicle coverage for U.S., Asian and European markets over 110 brands, which is continually updated
8. All Impressive Hardware, Realize Your Full Potential:

• Its fine-turned Android 9.0 KitKat allows fast boot-up within seconds and multitasking.
• Extraordinarily 8-core Cortex-A53 Processor (2GHz) boosts your speed of programming and diagnostics.
• The thin and light tablet-style design, with a capacitive touchscreen that is sensitive to your every gesture.
• Super-size & ultra-crisp 13.3” (1920*1080) touchscreen offers visually stunning view; gorilla glass provides exceptional damage resistance to the scratches.
• The internal 8G+256G onboard memory is a great plus for material storage.
• An 18,720Ah rechargeable lithium-polymer battery enables up to 20 hours of continuous operation.
• And thanks to the wireless scanning and Wi-Fi connection, you can stay connected and work from anywhere in the service bay.
• Real IP65 rated; 180° adjustable kickstand.
• X431 Remote Diagnose: If you need any remote help, give your mechanic access to the remote expert. Simply offer him the access code and he can perform one-for-one remote diagnose using any web browser (platform: remoteddiag.x431 .com), or via an X431 scanner. Unlike using the TeamViwer, this has not just realized the reality that a mechanic can diagnose an abnormal vehicle that is even thousands of miles away, yet faster, simpler, more stable, and subscription-free. Or, you can send us the detailed diagnostic report for better understanding your current issues at hand. We’ll be in touch to offer help 24/7.

LAUNCH TOP SCANNER WITH J2534 PROGRAMMING, LAUNCH X431 PAD VII ELITE AUTO DIAGNOSTIC SCANNER

ECU Programming & Coding. It’s Easier to Run

Reliable ECU Data Backup, Faster Recovery & Less Downtime

• When customizing your vehicle, there is always a question: will it be able to revert the changes in case of human error, system failure, or data loss that bricks the vehicle computer?
• This is where the “Backup/Recovery ECU Data” function can prove to be very useful.
• Unlike traditional car scanner backup methods that can be labor intensive and inconsistent, LAUNCH X431 PADVII provides a simple mechanism to back up all your ECU programming & coding data.
• It allows you to make a copy of your current Coding, Adaptations, and other info (such as Advanced ID and Live Data) of a selected control module, and save them as a file into your scan tool as a backup.
• To restore coding or programming values, just select the backup file you need and you’ll effortlessly get reverted back to the old settings/coding in a control module.
• For now this function is compatible with Ben.z all series, and B.M.W F/G/I chassis.
• **NOT universally compatible. Function menus may depend on vehicle’s make, model and year.

Programming Online for Benz & BMW, Save Your Labor Greatly

• LAUNCH stores the Benz & BMW’s massive programming data in the cloud, rather than relying solely on a hard drive, so you won't lose access if something happens to your hard drive.
• More, LAUNCH PADVII saves time to guide your programming directly. Unlike any scan tools before, it practically anticipates your next move by guiding you through every step you need to find the solution patch while avoiding the steps you don’t, within a highly intuitive user interface that’s simple to learn and operate.
• With this automatic Online Programming, you’ll have the confidence to tackle more challenges than ever before. The only requirements are a stable & solid internet connection, and an external battery charger for your successful operation.

>> Can I use the diagnostic tool to program Au.d.i, VW, Porsche … besides Benz and BMW?

• Answer: Yes, provided you have installed, downloaded the manufacturer’s programming software, and paid for the valid subscription.
• With SmartLink C VCI Box (compatible with J2534-1 & -2; value of 2000+ bucks), you can cost-effectively add new OEM applications for 30+ car brands, with no need to purchase separate, expensive OE scan tools for each brand.

>> What happens if I don't program a new ECU after installing it on my car?

• Answer: Nothing will happen, because the system doesn't know how to react, since the PROM that governs the circuits of ECU “what to do” is blank.
• It cannot command the injectors to open or the coil(s) to fire. It cannot command the fuel pump to send fuel. It cannot read the external temperature, or even the temperature of the coolant, because there are no instructions defining what is hooked to the ECU, and there is no information to tell the system when to open the injectors, or for how long.

Please note:

1. Online Programming: **Please reach us to get the "X431 PADVII online programming activation method".
2. J2534 Reprogramming: **Note: Reach us to get the J2534 Operation manual.

LAUNCH TOP SCANNER WITH J2534 PROGRAMMING, LAUNCH X431 PAD VII ELITE AUTO DIAGNOSTIC TOOL

Revolutionary Topology Module Mapping + 60+ Advanced Maintenance Services + 35+ Reset & Relearn Services

Revolutionary Topology Module Mapping

• It is the first application of topology module mapping in the field of automotive diagnostics. In terms of visual aspect, LAUNCH X431 PAD VII ELITE shows different health statuses in different colors and shows the structure of communication between modules. In the aspect of ease of use, it enables you to press the system module to access the system and display the relevant DTCs.

60+ Advanced Maintenance Services:

• Guided Functions: Skip the Security Access Code & Channel Number to perform matching, calibration, and basic settings for VW / Audi / Skoda / Seat; **NO extra costs.
• Component Matching: Rematch ECU (control module unit) after the replacement for VW / Audi / Skoda / Seat / BMW / Chrysler / GM / Ford / Opel / Mazda / Fiat / Honda / Nissan / Hyundai / Kia / Subaru etc.
• Online Parameterization: Reset all adaptive data in target systems after ECU module replacement; compatible with VW / Audi / Skoda / Seat.
• Online Calibration: For some car systems’ calibration; compatible with VW / Audi / Skoda / Seat.
• Online Account Login Service: Access to the login codes for coding, matching, and basic settings of all available systems.
• Programmable Module Installation (PMI): Ensure the correct software/calibration and configuration data are loaded onto the new module after replacement for Ford / Mazda.
• Power Balance: Identify the less productive cylinder for Chrysler / GM / Ford.
• Personalization: Compatible with BMW / Porsche / Toyota / Subaru.
• And many more are coming soon.

Cover the majority of makes and models worldwide up to 2019/2020/2022 for Oil Reset, Injector Coding, Brake Reset, SAS Reset, BMS Service, ABS Bleeding, Throttle Matching, TPMS Reset, Gear Learning, AFS Reset, Gearbox, Sunroof, SUS Reset, Windows Calibration, Seats Calibration, Language Change, A/F Reset, Coolant Bleed, Transport Mode, Adblue Reset, NOx Sensor Reset NOx, Stop/Start Reset, Headlamp Fitting, Seat Matching, Door & Window Initialization Study, Air Suspension Matching, Multimedia Video Reset, Cluster Reset, Immobilizer Service, Tire Change, and more.

LAUNCH TOP SCANNER WITH J2534 PROGRAMMING, LAUNCH X431 PAD VII ELITE AUTO DIAGNOSTIC SCAN TOOL

Multiple Advanced Functions Greatly Improve Work Efficiency

FCA Secure Gateway

LAUNCH X431 PAD VII ELITE automotive diagnostic scanner provides a trustworthy authority for technicians, car dealers, automotive engineers, and service shops to undo the SGW and perform all the necessary repair procedures.

Active Test / Bidirectional Control

LAUNCH X431 PAD VII ELITE performs the active test, which bypasses the onboard control systems to send commands to modules to perform specific tests. By monitoring their responses, you can precisely locate the faults, and shorten the troubleshooting time without tearing the vehicle apart. It can:

• Rolling up / down a window;
• Turning the fuel pump on and off;
• Cycling the a/c clutch on and off

Pin Detection

This module allows you to detect the voltage of the vehicle OBD II diagnostic socket pins and the supported protocol types to help technicians judge the OBD II diagnostic interface.

Note: Before performing this function, please make sure that SmartLink C is properly connected to the vehicle’s DLC port.

LAUNCH TOP SCANNER WITH J2534 PROGRAMMING, LAUNCH X431 PAD VII ELITE CAR DIAGNOSTIC SCANNER

Wide Vehicle Coverage

The newly upgraded LAUNCH X431 PAD VII ELITE has also been improved in terms of vehicle coverage. The vehicle coverage upgrade is not limited to a particular country but refers to globally broad compatibility for commercial and passenger vehicles. (If you need to diagnose commercial vehicles/trucks, you need to purchase HD software separately which comes with truck adapter accessories, and then activate the heavy-duty module on the pad vii elite tablet.)

It is compatible with ABARTH, ACURA, AUDI, ASTON MARTIN, BAIC, BENZ, BINGLEY, BMW, BRILLIANCE, BUGATTI, BUICK, BYD, CADILLAC, CHANG'AN, CHANGCHENG, CHANGHE, CHERY, CHEVROLET, CHRYSLER, CITROEN, CMC, DACIA, DAEWOO, DAIHATSU, DODGE, FAW, FERRARI, FIAT, FIAT (BRAZIL), FUKANG, FORD, FORD (AUSTRALIA / EUROPEAN), FOTON, GAZ, GM, GM (BRAZIL), GMSA, GONOW, HAFEI, HAIMA, HONDA, HORTON, HYUNDAI, INFINITI, INDIA FORCE, ISUZU, ISUZU(TL), IVECO, IZH, JAC, JAGUAR, JEEP, JIANGLING, KIA, KOWLOON, LANCIA, LAND ROVER, LEXUS, LIFAN, LINCOLN, LUXGEN, MAYBACH, MAHINDRA, MARTHA, MARUTI, MAZDA, MINI, MITSUBISHI, MVM, NISSAN, OPEL, PAZ, PERODUA, PEUGEOT, PORSCHE, PROTON, RENAULT, ROLLS-ROYCE, ROMEO, SAAB, SAIC, SAIC AND MG, SAIPA, SAMSUNG, SEAT, SEAZ, SGM, SGMW, SKODA, SMART, SSANGYONG, SUBARU, SUZUKI, TATA, TIANJIN, TOYOTA, TRANSPORTER&V-CLASS, UAZ, VAUXHALL, VAZ, VINFAST, VISUAL, VOLVO, VW, WEILI, XIAMEN, XIAOKANG, XINKAI, ZAZ, ZHONGSHUN, ZHONGXING, ZOTYE

Supports Extended Function Modules:

• VSP-600 VideoScope: for up-close visual inspections in confined areas.
• X-PROG & X-PROG3 Immobilizer: for key programming & IMMO service.
• S2-2 SensorBox: diagnose and simulate vehicle sensor faults quickly.
• O2-1 ScopeBox, Oscilloscope: quickly acquire the circuit signal, and slowly display the waveform for easier analysis.
• X-431 Wi-Fi Printer: print out diagnostic data & reports.
• X-431 TSGUN: activate all sensors, relearn & program LAUNCH sensors.
• BTS360 Bluetooth Battery Tester: get a thorough test of the vehicle battery.

**Need extra costs to buy these function modules.
